RD D-Pro ESC 40A is an advanced Electronic Speed Controller (ESC) designed for high-performance applications. Made in India, this model
significantly enhances thermal and current handling capabilities.
| S. No. | Parameter | Value | Remarks |
|---|---|---|---|
| 1. | Input Voltage | 2~6S LiPo | – |
| 2. | Continuous Current | 40A(With Active Cooling for 180s) | Tested in 10 m/s continuous airflow and 28℃ ambient Temperature |
| 3. | BEC Output Voltage | No | – |
| 4. | Operating Ambient Temperature | (-20℃) ~(+ 65℃) | – |
| 5. | Standby current (24V) | ≤ 25mA | – |
| 6. | Throttle Range(Can be Calibrated) | 1100us ~ 1900us | Calibration Enable |
| 7. | Recommended Throttle refresh frequency | 50Hz | – |
| 8. | Throttle I/P mode | PWM & Dshot300 | – |
| 9. | Over Temperature Protection | Yes | – |
| 10. | Overcurrent Protection | Yes | – |
| 11. | Stuck Rotor Protection | Yes | – |
| 12. | Waterproof Rating | No | – |
| 13. | Startup Protection | Yes | – |
| 14. | Invert Motor Spin | Yes | Configured using RD GUI |
| 15. | Telemetry | Yes | Voltage, Current, PCB Temperature, Motor, eRPM |
| 16. | Braking Feature | No | – |
RD D-Pro ESC 40A is an advanced Electronic Speed Controller (ESC) designed for high-performance applications. Made in India, this model
significantly enhances thermal and current handling capabilities.
