RD MI-5008 Brushless Motor is a lightweight and efficient brushless outrunner motor with a KV rating of 340KV, engineered to meet the rigorous demands of quadcopters and VTOL applications. Made in India, it features advanced cooling for reliable performance and durability under high-thrust conditions. The motor is designed for seamless compatibility with 15-inch to 18-inch propellers.
Multi-copter design recommendations
Quad-copter:
Maximum take-off weight for the drone: 7.62 KG
Hex-copter:
Maximum take-off weight for the drone: 11.78 KG
Oct-copter:
Maximum take-off weight for the drone: 15.42 KG
| Motor Type | Outrunner |
| KV Rating | 340KV |
| No of Slots / Magnet Poles | 24/28 |
| No load current | 1.5A |
| Motor Efficiency | 90.99% |
| Weight (Including Cable) | 135 grams |
| Voltage Range | 6S |
| Maximum Current (15 Sec) | 51A |
| Maximum Power (15 Sec) | 1224W |
| Motor Dimensions | 55.6mm |
| Motor length | 27mm |
| Motor Torque Constant (gm.cm/A) | 294.15 |
| Cable Type / Length | 15 AWG / 80mm |
| Copper wire Temperature Rating | 90 ℃ |
| Winding material | 100% Copper |
| IP Rating | IP34 |
| Maximum Operating Temperature of the Magnet | 150 ℃ |
| Recommended Propeller | 17*60 (Folding) |
