RD7006 230KV

RD7006 230KV

RD7006 230KV

230KV I 6S

Product Description

The RD 7006 is a 230 KV brushless motor for drones, with a thrust of 5 kgf.

Where the RD7006 fits

The RD7006 is a compact 230KV motor for 6S systems. Its datasheet lists 5 kgf of maximum thrust, 700 W maximum power, a 30 A peak current and a weight of 190 g. The recommended take-off weight is 2 kg, so it is aimed at small to mid-size multirotors, light inspection and mapping platforms, and training or development airframes that need good thrust for very little weight.

The recommended ESC is the RD A-Series ESC 60A and the recommended propeller is the RD 2480 Propeller. With a 24-inch folding propeller and a 230KV winding, the combination is meant for efficient, steady lift rather than aggressive manoeuvring.

How it compares

Among our UAV motors, the RD7006 is the step above the RD5008 340KV (340KV, 3 kgf, 135 g) when you want more thrust at the same battery size, and the step below the RD6218 160KV (160KV, 12.5 kgf, 12S). Choose it when 6S is your battery standard and weight is tight. See our propellers for matching sizes, or contact [email protected] to confirm a motor, ESC and propeller combination for your take-off weight.

Specifications

Product name RD 7006
Country of Origin  India
Maximum Thrust 5 kgf
KV Rating 230 KV
Motor Size  Ø76.2 X 25.2 mm
Stator Size Ø70 X 6 mm
Motor Weight  190 g
Cable Length 100 mm
Recommended Battery  6S
Recommended Take-off Weight 2kg
Maximum Power 700W
Peak Current  30A
Recommended ESC  A-Series ESC 60A (FOC)
Recommended Propeller  RD 2480

Engineering Data

Motor 7006 (V2), 230 KV
ESC XC U80 V2 80A
Propeller 24 × 80 (as listed: 2480)
Power supply 24 V DC
Voltage (V) Throttle % PWM (µs) Current (A) Power (W) RPM Thrust (gf) Efficiency (gf/W)
24 20 1200 0.5 12 807 184 14.8
24 30 1300 1.5 36 1289 524 14.7
24 38 1381 3.0 72 1526 1099 15.3
24 40 1400 3.5 84 1778 1101 13.1
24 45 1450 4.8 114 2011 1353 11.9
24 50 1500 6.2 150 2175 1688 11.3
24 55 1550 7.9 191 2521 2033 10.7
24 60 1600 10.2 245 2635 2433 9.9
24 65 1650 12.8 307 2757 2864 9.3
24 70 1700 15.7 375 2651 3245 8.7
24 80 1800 22.2 529 3244 4069 7.7
24 85 1850 25.7 609 3522 4446 7.3
24 87 1870 27.1 643 3460 4598 7.2
24 89 1890 28.3 669 3537 4673 7.0

Performance data tested at approximately 35 °C and 123 m above sea level in Lucknow, India.

2D CAD, 3D CAD files and datasheets for this product are available in the Downloads section.
